IKO Number: TLA 4020Z

Mass (Ref.): 49 g

Assembled inner ring: IRT 3520

Fw: 40 mm

D: 47 mm

C: 20 mm

Shaft dia. h6max.: 40 mm

Shaft dia. h6min.: 39.984 mm

Housing bore dia. N7max.: 46.992 mm

Housing bore dia. N7min.: 46.967 mm

Dynamic, C: 22.1 kN

Static, C0: 48.2 kN

Allowable rotational speed: 8500 rpm
